Metal Ductile Iron Tree Grating Grates For Park And Garden
Production Description
Tree pit grates, also known as tree pit covers or tree pit grilles,
are environmentally friendly facilities specifically used for tree
protection and landscape decoration. They are widely used in public
places such as urban roads, parks, squares, and residential areas.
Tree pit grates not only protect the soil at the roots of trees
from being compacted, but also keep the ground clean and beautiful.
At the same time, they have water permeability, air permeability
and load-bearing capacity. They are an important part of modern
urban greening and infrastructure. Tree pit grates are usually made
of ductile iron, composite materials or steel, and are produced
through high-precision processing technology. Its unique grid
design can not only meet the needs of healthy growth of trees (such
as water permeability and air permeability), but also play a
protective role to prevent tree pits from being damaged by
pedestrians or vehicles. Tree pit grates also support customized
designs, which can be matched with urban landscapes to enhance the
overall beauty.
Product Features:
(1) Protect trees and promote healthy growth
Tree pit grates provide good water permeability and air
permeability, ensuring that rainwater can penetrate into the root
soil and provide trees with necessary oxygen and moisture.
Prevent tree roots from being exposed, while preventing the soil
from being trampled or compacted, protecting the normal growth of
trees.
(2) High strength and durability
Tree pit grates made of ductile iron have high strength and
toughness, can withstand the load of vehicles and pedestrians, and
are not easily damaged.
Other tree pit grates such as composite materials have the
characteristics of corrosion resistance, aging resistance, and
non-deformation.
(3) Beautiful decoration
The surface of the tree pit grate can be designed with various
patterns, patterns and colors to coordinate with the surrounding
environment and landscape facilities, and enhance the overall
beauty of the city.
Support customized LOGO, city logo or project name to increase
visual recognition.
(4) Anti-slip design to ensure safety
The surface of the grate is usually designed with anti-slip
patterns to prevent pedestrians from slipping even in rainy and
snowy weather.
(5) Easy to maintain and clean
The tree pit grate is detachable, which is convenient for cleaning
fallen leaves, garbage and other debris in the tree pit.
The surface is resistant to stains and easy to clean, reducing the
cost of subsequent maintenance.
(6) Environmentally friendly materials
The tree pit grate produced by recycled materials is not only
environmentally friendly, but also economical and recyclable.
Manufacturing Process:
Material Preparation: High-quality pig iron and scrap iron are
melted together, with magnesium added to create a ductile iron
alloy.
Casting: The molten iron is poured into molds to form the basic
shape of the manhole cover. Sand casting is a common method due to
its precision and efficiency.
Heat Treatment: The cast pieces are treated with heat to improve
strength and flexibility.
Surface Coating: Anti-corrosive coatings are applied to ensure
longevity in various environments.
Quality Control: Each cover undergoes rigorous testing for
load-bearing capacity, tensile strength, and dimensional accuracy.
Company Introduction:
SND has been producing and selling metal goods for about 20
years.By using manufacturing techniques including sand casting,
lost wax casting, lost foam casting, and precision machining, the
company has been supplying goods made of materials like cast iron,
steel, stainless steel, aluminum, etc. Additionally offered are
surface finishing and assembly services.
Our company has successfully created products in a variety of
industries, including automotive, rail transportation, agricultural
machinery, chemical, energy, electricity, water, air compressor,
and construction, thanks to our consistent efforts over the past
few years.
Our factories' ISO9001-accredited quality control systems guarantee
a consistent and dependable quality for each and every component.
Spectrometer, ultrasonic, magnetic, permeability, elongation,
tensile/yield strength, and other inspections are carried out as
part of routine production procedures.
| Load Class | Applications |
|---|
| A15 | Sidewalks, green spaces, parks |
| B125 | Non-motorized lanes, residential areas |
| C250 | Parking lots, secondary roads |
| D400 | Urban main roads, motor vehicle traffic areas |
| E600 | Industrial parks, ports, areas for heavy vehicle traffic |
| F900 | Airport runways, docks, areas for ultra-heavy industrial equipment |
