Circle Ductile Iron Gully Grate For Tree Pond Grate

Production Description

A round tree grate is a circular tree grate with round planting holes. The planting holes are highlighted by two round slits. The tree grate visually appears to consist of three round elements. The openings in the tree grate ensure that the tree receives enough water to remain alive and growing. In addition, the tree grate protects the tree's roots from damage and ensures an even ground level around the tree. As tree grates are not only functional but also beautiful, Grijsen offers a range of tree grates. Each tree grate has its own pattern.

The root system of a tree can grow two to seven times larger underground than the tree itself above ground. This creates the risk of paving stones shifting, causing the ground around the tree to become uneven. Tree fences prevent this and ensure an even ground level around the tree. In addition, they protect the tree's roots from the risk of damage. Tree roots are fragile and can be damaged by heavy vehicles such as cars and trucks.

The round tree grates are made of 10 mm ductile iron and have a KTL coating. The outer ring of the tree grate is removable.

Production information

Manufacturing Process

Material Preparation: High-quality pig iron and scrap iron are melted together, with magnesium added to create a ductile iron alloy.

Casting: The molten iron is poured into molds to form the basic shape of the manhole cover. Sand casting is a common method due to its precision and efficiency.

Heat Treatment: The cast pieces are treated with heat to improve strength and flexibility.

Surface Coating: Anti-corrosive coatings are applied to ensure longevity in various environments.

Quality Control: Each cover undergoes rigorous testing for load-bearing capacity, tensile strength, and dimensional accuracy.

GROUP PROFILE

SND has been producing and selling metal goods for about 20 years.By using manufacturing techniques including sand casting, lost wax casting, lost foam casting, and precision machining, the company has been supplying goods made of materials like cast iron, steel, stainless steel, aluminum, etc. Additionally offered are surface finishing and assembly services.

Our company has successfully created products in a variety of industries, including automotive, rail transportation, agricultural machinery, chemical, energy, electricity, water, air compressor, and construction, thanks to our consistent efforts over the past few years.


Our factories' ISO9001-accredited quality control systems guarantee a consistent and dependable quality for each and every component.
Spectrometer, ultrasonic, magnetic, permeability, elongation, tensile/yield strength, and other inspections are carried out as part of routine production procedures.

SND Foundry have been specializing in the production and sales of manhole cover and gully grating, valves, pipe & pipe fitings and metal castings products nearly 20 years. It is located in Wu'an Industrial Park, Handan City, Hebei Province. The park is the largest mechanical casting spare parts processing industrial park in Handan, with a complete supporting industry chain and convenient transportation.

SND has fully passed the ISO9001 quality management system certification. During the production process, it implements a number of strict detailed standards and conducts full-process quality control. Our company has well-equipped chemical laboratories and physical performance laboratories. A complete set of testing equipment such as Direct Reading Spectrometer, Metallographic Microscope, Rockwell Hardness Tester, Universal Material Testing Machine, Non destructive testing(NDT), and Three-dimensional Coordinate Measuring instrument can be used to effectively control chemical composition and ensure mechanical performance.
